CURT A20 5th Wheel Hitch | 16140 | 20K | Industry-Standard Rails Mount

Name: CURT A20 5th Wheel Hitch | 16140 | 20K | Industry-Standard Rails Mount
Brand: CURT
SKU: 16140
Price: 1410.0 AUD
Availability: InStock

CURT A20 5th Wheel Hitch | 16140 | 20K | Industry-Standard Rails Mount

$1,410.00 AUD

~~$1,561.00 AUD~~ $1,410.00 AUD

Sale Sold out

Shipping calculated at checkout.

Product variants

Quantity

The CURT A20 5th Wheel Hitch (Part #16140) is a premium 20K 5th wheel hitch with the A-Series' patented articulating head and self-resetting handle — configured for universal industry-standard rail mounting. Configuration: Industry-Standard Rails Mount. A20 head #16540 + industry-standard 5th wheel legs — mounts to any industry-standard 5th wheel base rails (rails and brackets sold separately). Rated to 20,000 lb GTW / 5,000 lb vertical load. Compatible with most industry-standard 5th wheel bracket kits. Sidewinder pin box compatible. CURT limited lifetime warranty.

The CURT A20 Series — Premium 20K 5th Wheel Hitch

The CURT A-Series is CURT's premium 5th wheel hitch line — engineered with patented articulating head geometry, interlocking dual-jaw design, and self-resetting handle operation. The A20 is the 20,000 lb capacity variant — the step up from the A16 for larger 5th wheels, mid-size toy haulers, and heavier commercial trailers. Meaningful highlights:

20,000 lb gross trailer weight (GTW) — handles larger 5th wheel RVs, toy haulers, and heavier commercial trailers
5,000 lb vertical load capacity — 1,000 lb more than A16, meaningful for larger trailers with heavier pin weights
⭐ Patented articulating torsion head (Patent #8,827,298) — cast yoke with poly-torsion inserts suppresses shock loads and reduces noise
⭐ Self-resetting single-throw handle — pull once to couple/uncouple; handle automatically returns to ready-to-couple position after uncoupling
⭐ High-strength interlocking dual jaws — fully wrap the kingpin for minimal movement and noise
⭐ Three-position color-coded coupling indicator — red (uncouple) / yellow (couple) / green (tow) — visible from the truck cab
⭐ Extra-wide head opening — makes coupling easier, especially in low-visibility conditions
⭐ Sidewinder pin box compatible — approved for use with Sidewinder-style turret pin boxes
Four height adjustment settings (13"–17" range)
Carbide black powder coat finish
Backed by CURT's limited lifetime warranty (one-year finish, one-year parts)

Configuration Details

Configuration: Industry-Standard Rails Mount

A20 head #16540 + industry-standard 5th wheel legs — mounts to any industry-standard 5th wheel base rails (rails and brackets sold separately)

Rails and brackets are NOT included and must be purchased separately. Compatible with:

Any CURT industry-standard 5th wheel base rails (see #16100, #16104, #16200, #16204)
Custom under-bed brackets (vehicle-specific) — see #16430 (Ram) or #16911 (F-150)

⭐ Universal Industry-Standard Fit

Meaningful benefit vs vehicle-specific puck configurations: universal industry-standard base rail mounting works with virtually any truck (with appropriate custom under-bed brackets) — including trucks without factory puck systems, older model years, and cross-brand installations.

All A20 Base Configurations

#16540 — Hitch Head Only ($622.95)
#16140 — Industry-standard (rails sold separately) ($999.95) ⬅ THIS UNIT
#16141 — Rails included ($1027.95)

Have a Puck-Equipped Truck?

If your truck has a factory puck system, direct-fit puck A20 hitches are typically the easiest installation:

Need Sliding Operation?

A20 vs A16 — When to Step Up

The A20 and A16 share the same premium A-Series head design (articulating torsion, dual jaws, self-resetting handle, 3-position indicator, Sidewinder compatible). Meaningful A20 upgrades over A16:

20,000 lb GTW vs A16's 16,000 lb — handles heavier trailers
5,000 lb vertical load capacity vs A16's 4,000 lb — meaningful for larger 5th wheels with heavier pin weights
Same puck-system compatibility as A16 — uses the same puck legs (#16025, #16029, etc.) so upgrade paths are straightforward

Choose A20 if your trailer's GTW or pin weight is close to or above the A16's ratings. For a typical 32'–40' 5th wheel with a loaded pin weight over 3,500 lb, A20 provides meaningful headroom.

Need Even Higher Capacity?

The A20 is capped at 20,000 lb GTW. For larger 5th wheels and heavy toy haulers, CURT offers:

A25 (25K) — 25,000 lb GTW / 6,250 lb vertical load
A30 (30K) — Maximum A-Series capacity for luxury 5th wheels and heavy toy haulers
PowerRide (30K) — CURT's flagship — multi-directional head, strategic grip points, self-resetting handle

Each higher-capacity variant is available for the same puck-system trucks and universal industry-standard base rails.

Cross-Reference Part Numbers

Part Number: 16140
UPC: 612314161409
Head: A20 #16540

⚠️ Professional Installation Recommended

Installation involves under-bed bracket mounting, base rail installation through the truck bed, and hitch assembly. Installation should be performed by a qualified installer.
